COMPRESSED ASBESTOS FIBRE JOINTING SHEETS & GASKETS - Style 60 Acid
Compressed fibre jointing sheet with premium chemical resistant binders
Champion Style 60 Acid / Chemical is premium grade acid / chemical resisting gasket, which is intimately bonded with technical suitable premium raw materials to withstand the corrosive action of acids, alkali/chemicals.
Champion Style 60 Acid / Chemical jointing sheets are a price worthy quality of dependable performance, plus adaptability to many sealing requirements makes this ‘ACID’ Jointing the choice packing of plant engineers and maintenance men for last 6 decades, one of the largest selling product for CPI applications.
Champion Style 60 Acid / Chemical can be used as jointing for all acid and corrosion applications in Chemical Processing Industry.
This gasket is recommended for corrosive media, hot concentrated organic, inorganic and mineral acids including hydrochloric, sulphuric and nitric acids (chemical industry conditions).
Sheets, pre-cut gaskets, special density, thickness, shape or grade available on request.
| Available Sheet Sizes in mm (+/- 5%) | 1600 mm x 4000 mm |
|---|---|
| 1500 mm x 2000 mm | |
| 1600 mm x 2000 mm | |
| 2000 mm X 6000 mm | |
| Thickness (mm) | 0.5 mm; 0.75 mm; 1.0 mm; |
| 1.5 mm; 2.0 mm; 3.0 mm; | |
| 4.0 mm**; 5.0 mm** |
| Description | Standard Specs | Typical Values |
|---|---|---|
| Density | DIN 28090-2 | 1.85 - 2.0 g/cm2 |
| Tensile Strength | ASTM F 152 | ≥14 MPa / 140 Bar (2030 psi) |
| Compressibility | ASTM F 36 | 8% to 18% |
| Residual Stress | BS 7531 | ≥14 MPa / 140 Bar (2030 psi) |
| Gas Permeability | BS 7531 | <0.1 cc/min |
| Recovery | ASTM F 36 | ≥40% |
| Water Absorption | BS 7531 | ≤18% |
| Ignition Loss | DIN 52911 | ≤35% |
| Thermal Conductivity | - | 0.40 W/mK |
Champion Gasket
Style 60 Acid / Chemical
